We introduce an approach for damage detection in gearboxes based on the analysis of sensor data with the multi-resolution dynamic mode decomposition (mrDMD). The application focus is the condition monitoring of wind turbine gearboxes under varying load conditions, in particular irregular and stochastic wind fluctuations. We analyze data stemming from a simulated vibration response of a simple nonlinear gearbox model in a healthy and damaged scenario and under different wind conditions. With mrDMD applied on time-delay snapshots of the sensor data, we can extract components in these vibration signals that highlight features related to damage and enable its identification. A comparison with Fourier analysis, time synchronous averaging, and empirical mode decomposition shows the advantages of the proposed mrDMD-based data analysis approach for damage detection.

Offshore wind turbines intend to take a rapidly growing share in the electric mix. The design, installation, and exploitation of these industrial assets are regulated by international standards, providing generic guidelines. Constantly, new projects reach unexploited wind resources, pushing back installation limits. Therefore, turbines are increasingly subject to uncertain environmental conditions, making long-term investment decisions riskier (at the design or end-of-life stage). Fortunately, numerical models of wind turbines enable to perform accurate multi-physics simulations of such systems when interacting with their environment. The challenge is then to propagate the input environmental uncertainties through these models and to analyze the distribution of output variables of interest. Since each call of such a numerical model can be costly, the estimation of statistical output quantities of interest (e.g., the mean value, the variance) has to be done with a restricted number of simulations. To do so, the present paper uses the kernel herding method as a sampling technique to perform Bayesian quadrature and estimate the fatigue damage. It is known from the literature that this method guarantees fast and accurate convergence together with providing relevant properties regarding subsampling and parallelization. Here, one numerically strengthens this fact by applying it to a real use case of an offshore wind turbine operating in Teesside, UK. Numerical comparison with crude and quasi-Monte Carlo sampling demonstrates the benefits one can expect from such a method. Finally, a new Python package has been developed and documented to provide quick open access to this uncertainty propagation method.

Vibration-based structural health monitoring (SHM) of (large) infrastructure through operational modal analysis (OMA) is a commonly adopted strategy. This is typically a four-step process, comprising estimation, tracking, data normalization, and decision-making. These steps are essential to ensure structural modes are correctly identified, and results are normalized for environmental and operational variability (EOV). Other challenges, such as nonstructural modes in the OMA, for example, rotor harmonics in (offshore) wind turbines (OWTs), further complicate the process. Typically, these four steps are considered independently, making the method simple and robust, but rather limited in challenging applications, such as OWTs. Therefore, this study aims to combine tracking, data normalization, and decision-making through a single machine learning (ML) model. The presented SHM framework starts by identifying a “healthy” training dataset, representative of all relevant EOV, for all structural modes. Subsequently, operational and weather data are used for feature selection and a comparative analysis of ML models, leading to the selection of tree-based learners for natural frequency prediction. Uncertainty quantification (UQ) is introduced to identify out-of-distribution instances, crucial to guarantee low modeling error and ensure only high-fidelity structural modes are tracked. This study uses virtual ensembles for UQ through the variance between multiple truncated submodel predictions. Practical application to monopile-supported OWT data demonstrates the tracking abilities, separating structural modes from rotor dynamics. Control charts show improved decision-making compared to traditional reference-based methods. A synthetic dataset further confirms the approach’s robustness in identifying relevant natural frequency shifts. This study presents a comprehensive data-driven approach for vibration-based SHM.

This work is concerned with damage detection in a commercial 52-meter wind turbine blade during fatigue testing. Different artificial damages are introduced in the blade in the form of laminate cracks. The lengths of the damages are increased manually, and they all eventually propagate and develop into delaminations during fatigue loading. Strain gauges, acoustic emission sensors, distributed accelerometers, and an active vibration monitoring system are used to track different physical responses in healthy and damaged states of the blade. Based on the recorded data, opportunities and limitations of the different sensing systems for blade structural health monitoring are investigated.

Population-based structural health monitoring (PBSHM) provides a means of accounting for inter-turbine correlations when solving the problem of wind farm anomaly detection. Across a wind farm, where a group of structures (turbines) is placed in close vicinity to each other, the environmental conditions and, thus, structural behavior vary in a spatiotemporal manner. Spatiotemporal trends are often overlooked in the existing data-based wind farm anomaly detection methods, because most current methods are designed for individual structures, that is, detecting anomalous behavior of a turbine based on the past behavior of the same turbine. In contrast, the idea of PBSHM involves sharing data across a population of structures and capturing the interactions between structures. This paper proposes a population-based anomaly detection method, specifically for a localized population of structures, which accounts for the spatiotemporal correlations in structural behavior. A case study from an offshore wind farm is given to demonstrate the potential of the proposed method as a wind farm performance indicator. It is concluded that the method has the potential to indicate operational anomalies caused by a range of factors across a wind farm. The method may also be useful for other tasks such as wind power and turbine load modeling.

Sensor placement optimization (SPO) is usually applied during the structural health monitoring sensor system design process to collect effective data. However, the failure of a sensor may significantly affect the expected performance of the entire system. Therefore, it is necessary to study the optimal sensor placement considering the possibility of sensor failure. In this article, the research focusses on an SPO giving a fail-safe sensor distribution, whose sub-distributions still have good performance. The performance of the fail-safe sensor distribution with multiple sensors placed in the same position will also be studied. The adopted data sets include the mode shapes and corresponding labels of structural states from a series of tests on a glider wing. A genetic algorithm is used to search for sensor deployments, and the partial results are validated by an exhaustive search. Two types of optimization objectives are investigated, one for modal identification and the other for damage identification. The results show that the proposed fail-safe sensor optimization method is beneficial for balancing the system performance before and after sensor failure.

Wind turbine towers are subjected to highly varying internal loads, characterized by large uncertainty. The uncertainty stems from many factors, including what the actual wind fields experienced over time will be, modeling uncertainties given the various operational states of the turbine with and without controller interaction, the influence of aerodynamic damping, and so forth. To monitor the true experienced loading and assess the fatigue, strain sensors can be installed at fatigue-critical locations on the turbine structure. A more cost-effective and practical solution is to predict the strain response of the structure based only on a number of acceleration measurements. In this contribution, an approach is followed where the dynamic strains in an existing onshore wind turbine tower are predicted using a Gaussian process latent force model. By employing this model, both the applied dynamic loading and strain response are estimated based on the acceleration data. The predicted dynamic strains are validated using strain gauges installed near the bottom of the tower. Fatigue is subsequently assessed by comparing the damage equivalent loads calculated with the predicted as opposed to the measured strains. The results confirm the usefulness of the method for continuous tracking of fatigue life consumption in onshore wind turbine towers.
